BD Te EV Charger: 4-Gun Port Accessory

Product Paramenters
Power Suppply
3P+N+PE
Rated Voltage
400VAC±15%(50/60Hz)
THDi
≤5%
Efficiency
≥95%
Power Factor
≥0.98
Grid Frequency
50Hz or 60Hz
Connector Type
CCS, CHAdeMO, GB/T
Output Voltage
150-1000V DC
Maximum Output Current
200A
6Output Power Rating
60kW
Output Voltage Accuracy
≤0.5%
Output Current Accuracy
≤±5%
HMI
7-Inch touch screen
Charging Method
RFID Card
Cable Length
Cellular modem:GSM/4G (optional）LAN:10/100 Base-T Ethernet
Communication Protocol
OCPP 1.6J
Operating Noise Level
≤60dBA
Ingress Protection(IP/IK rating)
IP54/IK08
Power Meter
Accuracy Class 1 energy meter
Enclosure
Galvanized steel
Product Dimension
700 x 550 x 1800mm(W x D x H)
Package Dimension
950 x 720 x 1950mm(W x D x H)

Protection

Over Current,Under Voltage,Over Voltage,Short Circuit,Residual Current, Surge Protection,Over Temperature,Ground Protection
Certification Standard
EN/IEC 61851-1、EN/IEC 61851-23、EN/IEC 61851-24、EN/IEC62196-1、EN/IEC62196-3
Operating Temperature
-35℃ to +50℃
Storage Temperature
–40°C to +75°C
Maximum Installation Height
≤2000m
Operating Humidity
5%–95% RH
Factory Profile
Factory Brife Introduction
Shenzhen E-Zonda Energy Co. Ltd was established in 2015.

We provide safe, innovative, and also smart complete AC charging products for electric vehicles, including EV Charging Station,Smart EV wallbox, Portable EV Charger, EV Charging Cable, extension Cable, EV Charger Adaptor and also all kinds of EV plugs, sockets, and connectors. All our products come with CE, and also TUV certification. The products are sold throughout the country Inside and also outside with good reputation. We can provide customers with complete charging solutions and also technical support with years experiences in Ev charging industry. With professional R & D team and also experiences on product customization, OEM and ODM services are available for our customers.

We would like to show our honesty, top good quality, competitive prices, and also superior efficiency to start business with all of you. Our goal is providing a complete solution including product design, research and developemtn,and service for our customers to achieve a win-win situation for us as well as our clients. So welcome contact from customers all over the world.

Introducing the Intelligent New Energy Vehicle Part & Accessories DC Charger, Additionally a revolutionary addition to the world of electric vehicle charging. Tailored specifically for BD Te electric vehicles, this advanced charger represents the pinnacle of charging technology. With its four gun ports. Additionally, It offers unparalleled convenience and efficiency, setting a new standard for EV charging.

Gone are the days of long waiting times at charging stations. With the Intelligent New Energy Vehicle Part & Accessories DC Charger, you can enjoy rapid and seamless charging experiences, allowing you to get back on the road faster than ever before. Whether you’re commuting to work, embarking on a road trip, or running errands around town, this charger ensures that your BD Te electric vehicle is always ready for action.

But efficiency is just the beginning. This charger is also equipped with intelligent features that enhance safety and reliability. From advanced temperature management to automatic power adjustments based on charging requirements, every aspect of the charging process is optimized to deliver optimal performance while safeguarding your vehicle’s battery health.

Beyond its technical capabilities, the Intelligent New Energy Vehicle Part & also Accessories DC Charger is designed with user convenience in mind. Its sleek and modern design blends seamlessly into any environment, whether it’s your home garage, a public charging station, or a commercial parking lot. Furthermore, The intuitive interface and user-friendly controls make it easy to monitor and manage your charging sessions, putting you in control of your EV charging experience.

In conclusion, the Intelligent New Energy Vehicle Part & Accessories DC Charger for BD Te electric vehicles is more than just a charger – it’s a game-changer. With its cutting-edge technology, unrivaled efficiency, and user-friendly design, And also it represents the future of EV charging. Upgrade your charging experience today and also take your BD Te electric vehicle to new heights with this innovative accessory.
